Equipment features:
Two wire and one hard structure, fast response, fast feed, good dynamic performance and high positioning accuracy.
1. The basic design of the whole machine is fast and high speed, which guarantees the mass production, precision machining and maximum processing efficiency of parts.
2. Modular combination of efficient chip removal, rapid feed and spindle high-speed functions to meet customers' different processing needs.
3. The key components that affect the quality of the whole machine are imported high-quality accessories.
Equipment parameters：
| Entry name | VMC970L | VMC850L | VMC1060L | VMC1270L | |
| X-axis stroke | mm | 1100 | 800 | 1000 | 1200 |
| Y-axis stroke | mm | 600 | 500 | 600 | 700 |
| Distance from spindle end face to worktable | mm | 95-795 | 110-610 | 70-670 | 87-687 |
| Distance from spindle center to column guide rail | mm | 654 | 560 | 660 | 785 |
| Dimension of worktable | mm | 600*1200 | 500*1000 | 600*1300 | 700*1360 |
| Maximum bearing capacity of workbench | kg | 800 | 600 | 800 | 1000 |
| T-groove | 5-18 | 5-18 | 5-18 | 5-18 | |
| T-groove spacing | mm | 110 | 90 | 100 | 122 |
| Spindle speed range | rpm | 8000 | 8000 | 8000 | 8000 |
| Spindle taper hole/outer diameter | BT40/Ø150 | BT40/Ø150 | BT40/Ø150 | BT50/Ø150 | |
| X/Y axis rapid feedrate | m/min | 36 | 36 | 30 | 30 |
| Z-axis rapid feedrate | m/min | 24 | 24 | 20 | 20 |
| feed rate | mm/min | 1-15000 | 1-15000 | 1-15000 | 1-15000 |
| Track specification | X45Y45 | X35Y45 | X45Y55 | X55Y45*4 | |
| Magazine capacity | 20/24 | 20/24 | 20/24 | 20/24 | |
| ool maximum diameter/length/mass | mm/mm/kg | 78/300/12 | 78/300/12 | 78/300/12 | 125/300/12 |
| Maximum diameter/length of tool (adjacent empty tool) | mm/mm | 150/300 | 150/300 | 150/300 | 150/300 |
| Spindle motor power | kw | 7.5/11 | 5.5/7.5 | 7.5/11 | 15/18.5 |
| Input power | 50HZ 380V | 50HZ 380V | 50HZ 380V | 50HZ 380V | |
| Overall dimensions (L * W * H) | mm | 3400*2650*2850 | 2805*2300*2600 | 3400*2750*2800 | 4500*3500*3700 |
| Net weight of machine tool (about weight) | kg | 6200 | 5800 | 7200 | 9200 |
